Products
Spacer
Brand : Xingming
Standard: GB/T 20065-2016r
Type: Hot Rolled
Material : Carbon Steel; PE
Quality Control: 100% quality inspected
Application: Post-Tensioning; Formworks; Geotechnical; Ground Anchors Soil Nailing; Tunneling
Description
marker
PRODUCT DESCRIPTION
External Spacer or Centralizer is used in centralize the thread bar inside the middle of the drill hole.
Specification:
1. External Spacer: The strap design makes the installation simply and easily, there are many pins inside the spacer, and the pins can lock the corrugated sheathing into the pitch makes the spacer immovable.
2. Strap Centralizer: The strap design makes the installation simply and easily, there are many pins inside the spacer, and the pins can lock the rebar into the pitch makes the centralizer immovable.
3. Olivary Centralizer: The olivary shape design makes the installation simply and easily ,there are six lockers on the centralizer, you can assemble the centralizer as buckle ,and there are many pins inside the wall, the pins can fasten the thread bar into the pitch, and this makes the centralizer immovable on the place of the rebar.
4. Lantern Centralizer: Lantern centralizer is used in centralizer the thread bar inside the middle of the drill hole.
Typical Applications:
1. Micro pile
2. Deep foundstion pit
3. Soil Nailing
